Compact Micro CT System
Top Performance
- Micro-focus Generators: Outstanding CT Resolution 2 μm
- High speed Detector: Fastest scan 6 sec.
High Flexibility
- Large inspection volume (ØxH): 185 mm x 390 mm
- Easy integration: Small footprint - Plug & play
- Designed for multiple applications: Different configurations available
Maximum Efficiency
- Enhanced mechanics: long-term stability granite axes
- Automated scanning reconstruction and inspection workflow
- Multiple acquisition modes: Conventional, helical, shift, stack...
- High availability: low maintenance downtime
Overview
RX SOLUTIONS X-ACT SOFTWARE FEATURES
X-Act Software:
- Independent plugins to drive generator(s), imager(s), axes
- Other plugins available for: dimensional measurements, video sequence acquisition, image filtering and processing, image export
CT Acquisition:
- CT Acquisition:
- Advanced plugin with options (360° rotation, helical, continuous rotation, laminography)
- Learning/Macros mode from automated workflow
CT Reconstruction:
- GPU implementation including various filters
- Post-processing software:
- 3D vizualisation, metrology, CAD comparison, defect analysis: in option
Technical Specifications
SYSTEM SPECIFICATIONS
Scanning Capabilities
Highest resolution: 2 μm (JIMA & QRM Charts)
Maximum scanned volume (ØxH) (The sample size can exceed the maximum scanned volume): 185 mm x 390 mm
Maximum sample weight: 5 kg
Mechanical Specifications
Cabinet dimensions (HxWxD): 1865 mm x 1325 mm x 890 mm
Total weight of the system: 1020 kg
Vertical Axis: 300 mm
Lateral Axis: 200 mm
Zoom Axis: 466 mm
Generator to detector distance: 590 mm
CT SPECIFICATIONS
X-ray Generator
Microfocus sealed tube: Option 1
Maximum voltage: 110 kV
Maximum power: 16 W
Minimum focal spot size: 2 μm
Microfocus sealed tube: Option 2
Maximum voltage: 130 kV
Maximum power: 39 W
Minimum focal spot size: 5 μm
Microfocus sealed tube: Option 3
Maximum voltage: 150 kV
Maximum power: 75 W
Minimum focal spot size: 5 μm
X-ray Detector
Flat panel (Other detectors available on request)
Active area: 20 cm x 25 cm
Pixel pitch: 127 μm
Pixel matrix: 1920 x 1536
Frame rate: 1-60 fps
